  1.  #Product Info#

    The NW650 is part of the high quality range of Industrial Water Filters from Cintropur, designed for filtering clear and slightly contaminated water. Designed for filtering out solid particles (earth, sand, rust, etc,) suspended in the water.

    There are three models with the Industrial range offering high flow rates with compact sizing and low cost

    NW650 Technical Data

    Pipe Diameter

    2 1/2"

    Average Flow (m³/h)

    25

    Min Pressure (bar)

    1

    Max Pressure (bar)

    16

    Max Temperature (°C)

    50

    Weight (kg)

    7

    Standard Filter Sleeve

    25µ

    Filtration Surface (cm²)

    1288


    Main advantages

    • double stage of filtration (centrifugal flow thanks to the vane + filtering sleeve)
    • filtration practically without accumulation
    • low pressure drop
    • high and constant flow rate
    • wide choice of filtering fineness ranging from 1 to 300 microns
    • sealing guaranteed thanks to the O-ring system
    • fast and easy rinsing thanks to the drain valve
    • long lifetime and uninterrupted spare parts supply
    • reduced need for maintenance

    Cintropur water filters are fitted with a 25 micron filter sleeve as standard issue, a system of interchangeable and disposable sleeves offer filtration at 1, 5, 10, 25, 50 and 100 micron. 150 & 300 micron nylon (washable) sleeves are also available for these models.

    This option comers complete with the Filter Housing Spanner. Please click here for Wall Mounting Bracket  sold separately.

    The connection options range from 1" to 1.5", using a connector set that allows placement and removal of the filter without requiring any tools.

    Bowl transparency enables visual inspection of impurity deposits.

    Recommended replacement of filters at least twice a year for drinking water.

    Filter sleeves come in a flat pack of 5.


  2. #Brochure#
  3. #Data Sheet#


Cintropur Industrial Water Filter NW650 - 25m³/h / 2 ½"

Cintropur
£ 295.00
9000g
